Learn More Releted CasesOur ER430-445FSP-1 flexible PV module, specially developed for low load bearing extensive photovoltaic projects, such as standing seam roofing system, flat roofs with waterproof coils and curved roofs, which offers a number of advantages. Due to its low weight of only 3.8 kg/m², suitable for 90% of industrial and commercial roofs, in addition, our innovative bonding method enables a significant reduction in assembly time,which means that your industrial and commercial areas can be quickly and easily converted into energy sources with much lower installation materials cost and labor cost.
ER430-445FSP-1 flexible PV module, offers an output of 445 watts peak power(Wp). The junction box usually be mounted both in the back and front of the module according to your need.
It can be directly bonded to the roof with silicone structural adhesive（The width of the vertical seam must be at least 10mm）.
For less 10mm vertical seam, aluminum square pipe can be used for support, the specific installation method can consult our customer service.
It can be directly bonded to the roof with silicone structural adhesive. Please send us the installation area drawings and we will provide you with specific solutions.
Learn More with Ericsity PV Solution whatsapp
Lightweight solar panels usually be used for low bearing and can not be drilled roof, the weight is only 5.6kg/m2, the solar cells are protected by organic glass as same as the conventional glass solar panels. The frameless design not only significantly reduces weight, but also makes it harder for dust to stay at the bottom of the PV modules. Different from flexible solar modules, ER315-335LT/ER420LT still retains the characteristics of rigid solar modules, and its service life and safety are completely consistent with traditional glass modules.
Learn More with Ericsity PV Solution whatsapp
Bifacial solar panels capture light not only from the front of the panel but also from the back. With double-sided solar panels (PV), we increase the electricity yield by about 10 to 20%.These solar cells have an almost identical metal grid at the front and back, with more than 95% of both sides available to capture light.
Bifacial panels are installed in standard PV power plants, but also in emerging market segments. Think of PV integrated into the infrastructure, such as in noise barriers. Or floating solar panels on open water or in combined hydro and aquaculture farms. Another application is in combination with solar tracking systems, where you can virtually add up the additional yield of the solar tracking system and the bifacial panels. This last option also offers many possibilities to vary the irradiation under and between the panels. Ideal for agriculture or nature conservation.
Learn More with Ericsity PV Solution whatsapp
Perfectly integrated PV modules DAS Energy modules are designed in such a way that they can be integrated into any aluminum roof and facade system. An example for the use of DAS Energy PV modules on standing seam roof is shown at the modern and largest waste incineration plant in Kraków, Poland. The 12x2M DAS Energy PV modules are […]
Learn More with Ericsity PV Solution whatsapp
specially designed for standing seam roofing Our 12x2M project module was specially developed for roof-integrated PV solutions such as standing seam systems (e.g. Kalzip AluPlusSolar). The 120 Wp modules are glued directly onto the roof profiles between the metal seams. Large industrial areas and facades can be converted into large solar power plants in this way. This module is also quick and […]
Learn More with Ericsity PV Solution whatsapp
for large photovoltaic projects Our 11×6 project module was specially designed for large photovoltaic projects. The weight advantage (only 3.3 kg/m2) allows easy handling during installation and with the bonding technology, the installation time is significantly reduced. Thus, large industrial roof areas can be quickly and easily converted into energy roofs. The 11×6 project module is equipped with 66 monocrystalline silicon cells and with […]
Learn More with Ericsity PV Solution whatsapp
Do you want to learn more about ericsity Energy Photovoltaic's systems or talk to us about your PV project? Simply complete the contact form and select your preferred contact method. Our service team will get in touch with you as soon as possible. If you need further information or have any other questions, contact us using the options below.
